  • Non-Sideshifting

Non-Sideshifting

BrandLDSJ

NameTurning Fork

Applicationforklift

We're here to help:Easy ways to get the answers you need.

Non-Sideshifting
Specifically designed for all tonnages of forklifts with international standard.With the forklift attachments, forklift will play its role to the best.



Technical Parameters

型号 载荷能力/ 夹臂 货叉 失载距 水平 自重 叉长 框架 安装
Model 载荷中心Capacity/ 张距 张距 Effective 重心 Weight Fork 宽度 等级
  Load Clamping Range Forks Thickness Horizontal   Length Frame (旋转器/
  Center   Range   Center     Width 货叉)
          Of       Mounting
          Gracity       Class
                  (Rotators/
                  Tine)
    D A C CGH   L B
  KG/MM MM MM MM MM KG MM MM
G15B20-174A10 2000/500 440-1740 560-1860 235 265 580 900 1040 2
G15B20-174B10 3
G15B20-174A20 2000/500 440-1740 560-1860 235 280 590 1000 1040 2
G15B20-174B20 3
G15B20-174A40 2000/500 440-1740 560-1860 235 300 600 1200 1040 2
G15B20-174B40 3

FEATURES

Forklift attachments are an unique tool for forklifts
Characte
r:
1.More convenient and safe
2.Multifunctional with different usages
3.Easy to assemble and dissemble
4.Coordinate with forklifts wonderfully

Applications

After-sales service

Warranty policy :
If anything go wrong within 12months from the date of purchase we will pay for parts to have the repairs conducted with shipping expenses paid by the buyer.
We will not be responsible for damage cause by the user or owner or lack of required maintenance
or abuse.
