"Side Load Forklift Electric – Durable Heavy-Duty Sideloader for Industry"

Technical Parameters

Model			CCD-80	CCD-100	CCD-120
Carrying capacity (load centre 0.6m)			8000kg	10000kg	12000kg
Max.lift weight			3.6m	3.6m	3.6m
Fork free lift height			0.4m	0.4m	0.4m
Max.lift speed			0.23m/s	0.24m/s	0.24m/s
Max.traveling speed			14km/h	15km/h	15km/h
Fork tilt anger (front/rear)			5°/3°	5°/3°	5°/3°
Min.turning radius			4.8m	5.9m	5.9m
Gradeability (laden)			13%	13%	13%
Min.ground clearance (laden)			0.18m	0.22m	0.22m
Overall dimension	Length		5.4m	6.2m	6.2m
	Width		2.3m	2.6m	2.6m
	Heigth	Fork in the lowest position	2.93m	3.45m	3.45m
	Heigth	Fork in the highest position	4.7m	5.23m	5.23m
Wheel base			3.05m	3.7m	3.7m
Truck width			1.886/1.601m	2.2/2.11m	2.2/2.11m
Platform height (laden)			1.08m	1.34m	1.34m
Platform width			1.47m	1.76m	1.76m
Fork length			1.45m	1.65m	1.65m
Max.fork spacing			1.167m	1.31m	1.31m
Tyres size			9.00-16-14PR	12.00-20-18PR	12.00-20-18PR
Weight (unladen)			11000kg	18000kg	18000kg
Volts AH battery			96V/920Ah	120V /1200AH	120V/1200AH
Traction motor			35kw	50kw	50kw
Pump motor			25kw+25kw	2*25kw	2*25kw
Control system			America Curtis	America Curtis	America Curtis
intelligent charging machine			96V/200A	120V/300A	120V/300A

FEATURES

1.High-Capacity Battery Options. Optional Lithium Iron Battery to meet different requirements.
2.Wide Lifting Height Range. Lifting height from 3600mm to 6000mm, suitable for various working conditions.
3.Electric side loaders produce zero emissions, making them environmentally friendly and suitable for indoor use.
4.electric sideloader generally have lower operating and maintenance costs compared to internal combustion forklifts..
5.Electric Side Loading Forklift Truck operate quietly, reducing noise pollution in the workplace.
6.Strong Mast Reach and Ground Clearance. Mast forward distance: 1200mm, Ground clearance: 160–205mm, ideal for different terrain conditions.
7.Excellent Gradeability. Maximum gradeability of 13% for smooth operation on slopes.

APPLICATION

After-sales Service

24-Month or 2,000 Work-Hour Warranty:
Your investment is protected for two years or up to 2,000 hours of operation on all major components, including the rugged frame, durable drive axle, high-strength wheels and rims, powerful brakes and brake pumps, responsive steering axle and steering cylinder, efficient hydraulic pump, precision speed limit valve, sturdy forks, as well as the lift and tilt cylinders, and advanced control valves.

12-Month or 1,200 Work-Hour Warranty:
For one year or 1,200 work hours, we cover essential systems such as the robust engine, reliable hydraulic gearbox, dependable battery, intuitive instrument panel, fan belt, all switches, both inner and outer friction plates, high-performance generator and starter, durable water tank, and the complete hydraulic pipeline.Our dedicated team of sales professionals and technical experts is always ready to guide you in choosing the perfect forklift for your needs.
We are committed to delivering unmatched customer service, offering competitive pricing, ensuring swift delivery, and providing a comprehensive range of top-quality products.
Your satisfaction is our highest priority.
