7 ton forklift
ModelFD50,FD60,FD70
Capacity5000kg,6000kg, 7000kg
Load center600mm
Lift height3000mm
Fork size(LxWxH)1220x150x60mm,1220x150x60mm,1220x150x70mm
We're here to help:Easy ways to get the answers you need.
- 7 Ton Diesel Forklift
- 7 Ton Forklift for Sale – Ideal for Warehouse, Construction, and Port Operations
7 ton forklift specifications
|
Model |
|
FD70 |
|
Brand (OEM acceptable) |
|
FLIFT |
|
Power Source |
|
Diesel |
|
Capacity |
kg |
7000 |
|
Load center |
mm |
600 |
|
Lift height（Duplex wide-view） |
mm |
3000 |
|
Fork size(LxWxH) |
mm |
1220*150*70 |
|
Mast tilt angle(F/R) |
Deg |
6°/12° |
|
Length to face of fork |
mm |
3560 |
|
Overall width |
mm |
2010 |
|
Mast lowered height |
mm |
2500 |
|
Mast extended height |
mm |
4380 |
|
Overhead guard height |
mm |
2470 |
|
Turning radius |
mm |
3350 |
|
Min. right angle aisle width |
mm |
3040 |
|
Front overhang |
mm |
595 |
|
Ground clearance |
mm |
200 |
|
Wheelbase |
mm |
2250 |
|
Travel (no load) |
km/h |
26 |
|
Lifting (full load) |
mm/s |
460 |
|
Gradeability(laden) |
% |
20 |
|
Service weight |
kg |
9750 |
|
Front tire |
|
8.25-15-14PR |
|
Rear tire |
|
8.25-15-14PR |
|
Battery (voltage/capacity) |
v/ah |
(12V/80Ah)*2 |
|
Engine model |
|
ISUZU-6BG1 |
|
Engine rated output/r.p.m |
kw |
82.3/2000 |
|
Engine rated torque/r.p.m. |
n.m |
416/1400-1600 |
|
Engine No.of Cylinder |
|
6 |
|
Bore x stroke |
mm |
105x125 |
|
Displacement |
cc |
6494 |
|
Fuel tank capacity |
L |
140 |
FEATURES
Large ton internal combustion forklift
Character:
1.Scientific ergonomics design
2.Adjustable safety seat
3.Wide-view mast
4.High- mount exhaust system
5.Flexible steering system
6.Power-assisted brake
7.Optimal heat radiating& air duct system
8.Hydraulic transmission system
9.Easy available toolbox
10.Maintenance-free imported battery
11.Double air filter system (pre-filter and air-filter)
Excellent performance makes goodsense forklift to be the prior choice for clients.
Applications
.jpg)
24-Month or 2,000 Work-Hour Warranty:
Your investment is protected for two years or up to 2,000 hours of operation on all major components, including the rugged frame, durable drive axle, high-strength wheels and rims, powerful brakes and brake pumps, responsive steering axle and steering cylinder, efficient hydraulic pump, precision speed limit valve, sturdy forks, as well as the lift and tilt cylinders, and advanced control valves.
12-Month or 1,200 Work-Hour Warranty:
For one year or 1,200 work hours, we cover essential systems such as the robust engine, reliable hydraulic gearbox, dependable battery, intuitive instrument panel, fan belt, all switches, both inner and outer friction plates, high-performance generator and starter, durable water tank, and the complete hydraulic pipeline.
We are committed to delivering unmatched customer service, offering competitive pricing, ensuring swift delivery, and providing a comprehensive range of top-quality products.
Your satisfaction is our highest priority.
