diesel forklift truck,6 ton forklift,forklift 6 ton

Technical Parameters

Model		FD60
Brand (OEM acceptable)		FLIFT
Power Source		Diesel
Capacity	kg	6000
Load center	mm	600
Lift height（Duplex wide-view）	mm	3000
Fork size(LxWxH)	mm	122015060
Mast tilt angle(F/R)	Deg	6°/12°
Length to face of fork	mm	3450
Overall width	mm	2010
Mast lowered height	mm	2500
Mast extended height	mm	4380
Overhead guard height	mm	2470
Turning radius	mm	3250
Min. right angle aisle width	mm	2960
Front overhang	mm	590
Ground clearance	mm	200
Wheelbase	mm	2250
Travel (no load)	km/h	26
Lifting (full load)	mm/s	500
Gradeability(laden)	%	20
Service weight	kg	9150
Front tire		8.25-15-14PR
Rear tire		8.25-15-14PR
Battery (voltage/capacity)	v/ah	(12V/80Ah)*2
Engine model		ISUZU-6BG1
Engine rated output/r.p.m	kw	82.3/2000
Engine rated torque/r.p.m.	n.m	416/1400-1600
Engine No.of Cylinder		6
Bore x stroke	mm	105x125
Displacement	cc	6494
Fuel tank capacity	L	140

FEATURES

Large ton internal combustion forklift
Character:
1,Wide view mast
Wide-view mast gives the operator and enhanced forward visibility,which adds great to the efficiency and safety of operator.
2,Powerful engine
The powerful engine ensures our trucks high handling performance and offers an intrinsical safety and efficient operation.
3,Solid overhead guard
Specially designed solid overhead guard provides additional security for the operator
4,Reliable instruments
The instruments offer an easy access to the working condition of the truck,thus makes handling process more efficient and safe.
5,Ergonomics seat
Designed according to ergonomic principles,makes operation much comfortable and also relieves the fatigue caused by long time continuous operation.
6,Super low and non-slip step
Supper low and non-slip make operating convenient and safe.

Applications

Warranty and continuous original spare parts supply:
14 months or 1500 work-hour warranty period:
Frame, drive axle, wheel, rim, brake, brake pump, steering axle, steering cylinder, hydraulic pump, speed limit valve, fork, lift cylinder, tilt cylinder, control valve, hydraulic pipeline, water tank.
12 months or 1200 work-hour warranty period:
Engine ,hydraulic gear box, battery, instrument panel. Fan belt, all switches, plate friction outside and inside, generator and starter.
Our staff of sales and technical support is available to help you in selecting the right forklift, we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and a comprehensive product supplying. Our ultimate goal is your satisfaction！

Inquiry

6Ton Forklift
