Technical Parameters

Technical Parameters of FLIFT 2ton-3ton stand up counterbalance forklift
1	Model		CDD20B-45	CDD30B-60
2	Rated load capacity	kg	2000	3000
3	Maximum lift height	mm	4500	6000
4	Capacity at the max lifting height	kg	500	500
5	Load center	mm	460	460
6	Tires		Non-marking tires	Non-marking tires
7	Fork size	mm	92012040	92012240
8	Mast type		3-stage full-free mast	3-stage full-free mast
9	Fork adjustment range	mm	265-920	300-720
10	Overall length (includes fork length)	mm	2740	3290
11	Full width front/rear	mm	1080	1080
12	Mast closed height	mm	2100	2650
13	Free lift height		1532	1625
14	Overhead guard height	mm	2260	2280
15	Mast Maximum extended height	mm	5532	6985
16	Turning radius	mm	1550	1550
17	Maximum travel speed	Km/h	4.0/5.0	4.0/5.0
18	Grade-ability	%	5/10(Full laod/no load)	5/10(Full laod/no load)
19	Service Weight	kg	3900	4150
20	Drive wheel	mm	343*135	343*135
21	Front wheel	mm	16*7-10.5	16*7-10.5
22	Minimum ground clearance	mm	90	90
23	Battery voltage/capacity	V/Ah	48/400(Lead-Acid Battery)	51.2/600 (Lithium battery)
24	charger voltage/capacity	V/Ah	48/400	48/200
25	Lifting motor	KW	8.6	8.6
26	Driving motor	KW	6.5	6.5
27	Steering type		Electronic steering	Electronic steering

FEATURES

Stand Up Counterbalance Rider Forklift
Character:
1.Side standing type design and wide view mast.
2.With an 1550mm turning radius,FLIFT stand up electric forklift operates seamlessly in narrow aisles.
3.USA Curtis brand controller system.
4.Multi-function integrated electromagnetic joystick,precise, ergonomic control for all movements.
5.Equipped with standard No-Marking solid tire.
6.AC drive motor,Motor free-maintain.
7.Multi-functional instrument and leisure backrest.
8.Electronic steering/electromagnetic brakes,and cylinder safety shut-off valve device.
9.Optional lithium battery and side shifter device.
10.Emergency reverse anti-collision device,emergency power cut-off switch,Automatic deceleration in corners.

Electric 3 Wheel Stand-Up Forklift

Applications

Stand up counterbalance forklift price Counterbalanced Trucks stand up rider forklift

After-sales Service

24-Month or 2,000 Work-Hour Warranty:
Your investment is protected for two years or up to 2,000 hours of operation on all major components, including the rugged frame, durable drive axle, high-strength wheels and rims, powerful brakes and brake pumps, responsive steering axle and steering cylinder, efficient hydraulic pump, precision speed limit valve, sturdy forks, as well as the lift and tilt cylinders, and advanced control valves.

12-Month or 1,200 Work-Hour Warranty:
For one year or 1,200 work hours, we cover essential systems such as the robust engine, reliable hydraulic gearbox, dependable battery, intuitive instrument panel, fan belt, all switches, both inner and outer friction plates, high-performance generator and starter, durable water tank, and the complete hydraulic pipeline.Our dedicated team of sales professionals and technical experts is always ready to guide you in choosing the perfect forklift for your needs.
We are committed to delivering unmatched customer service, offering competitive pricing, ensuring swift delivery, and providing a comprehensive range of top-quality products.
Your satisfaction is our highest priority.
