FLIFT 7 Ton All Rough Terrain Forklift

Technical Parameters

Specifications		FDR70-A
Lifting Performance	Forklift Type	Articulated Rough Terrain
	Rated Lifting Capacity	7ton @ 600 cm Load Center
	Forklift Length	1520 mm
	Max. Lifting Height	3000 mm
Dimensions	Overall Length	5600 mm (exclusive of fork)
	Overall Width	2200 mm
	Over Height	3300 mm (To the cabin rooftop)
	Wheel Base	2650 mm
	Wheel Tread	1830 mm
Power Train	Engine Make	Chinese Dongfeng Cummins-Euro II
	Engine Model	C-150 / In-line / 110 kW
	Transmission	Torque-convertor transmission
	Gear shifts	Power shifted 4F and 2R
	Driving Type	All-time 4 x 4
	Steering Type	Hydraulic-driven articulated
Travel Performance	Service Weight	12500 kg
	Traction	100 kN
	Max. Gradeability	35°
	Max. F /R Speed	36 /22 km/h
	Min. Turning Radius	5500 mm
	Max. Ground Clearance	316 mm
	Turning Angle	35°
Hydraulic System	Hydraulic Pressure	17 Mpa
	Working Speed	2200 rpm
	Cylinder Drifting	≤12.5 mm/h

1: High Position Intake and Exhaust System:
vertical exhaust with good drainage performance, provide all weather operations.
Vertical exhaust effectively prevent ground dust and rain from entering the inlet.

2: Super High Ground Clearance:
front and rear wheels use deep-pattern widening off-road vacuum tires,
with strong off-road capability, excellent vehicle stability
and shock absorption.Steering axle swings up to 7,
good maintaining grip on rugged mountain or muddy terain.
350 mm ground clearance, strong pass ability.

3: High Strength Overhead Guard:
standard overhead guard and full cabin for options,
cabin can equip with heater and air-conditioner.
Top cover adopts high-strength steel plate stamping.

4: Reliable Lifting System:
wide view mast prepare driver perfect view,
compare with normal mast it's 10% wider, which provide more efficient and safety.

5: Excellent Lighting System:
the full machine equipped with LED lights, long energy consumption, long service lift and etc.

After-sales Service

24-Month or 2,000 Work-Hour Warranty:
Your investment is protected for two years or up to 2,000 hours of operation on all major components, including the rugged frame, durable drive axle, high-strength wheels and rims, powerful brakes and brake pumps, responsive steering axle and steering cylinder, efficient hydraulic pump, precision speed limit valve, sturdy forks, as well as the lift and tilt cylinders, and advanced control valves.

12-Month or 1,200 Work-Hour Warranty:
For one year or 1,200 work hours, we cover essential systems such as the robust engine, reliable hydraulic gearbox, dependable battery, intuitive instrument panel, fan belt, all switches, both inner and outer friction plates, high-performance generator and starter, durable water tank, and the complete hydraulic pipeline.Our dedicated team of sales professionals and technical experts is always ready to guide you in choosing the perfect forklift for your needs.
We are committed to delivering unmatched customer service, offering competitive pricing, ensuring swift delivery, and providing a comprehensive range of top-quality products.
Your satisfaction is our highest priority.
