2ton roll and reel electric pallet truck
Fork length 1400mm
Rated Capacity2000KG
Load Centre500mm
Lifting height 55mm
Battery Capacity24v/210ah
We're here to help:Easy ways to get the answers you need.
- 2 Ton Roll and Reel Electric Pallet Truck–High Capacity & Easy Operation
- Equipped with a reliable America Curtis controller, AC motor, and double cylinder design, this Reel pallet truck ensures stable lifting, smooth handling, and long-lasting performance. Perfect for paper rolls, film reels, and other cylindrical materials in warehouses and factories.
Technical Parameters
|
Model |
CBD20 |
Battery Capacity |
24V/210Ah |
|
Lift height |
55mm |
Drive Motor |
1.6kw |
|
Rated Capacity |
2000kg |
Lift Motor |
0.8kw |
|
Self weight |
660kg |
Controller |
American Curtis |
|
Dimensions (length*width*height) |
1875*1170*1530 |
Driving speed |
4.8km/h(Full-loaded） |
|
Load center |
500mm |
|
|
|
Minimum turning radius |
1730mm |
|
|
|
Fork length |
1400 |
|
|
FEATURES
1.AC drive motor,dual cylinders design;
2.High capacity 210AH maintenance free battery;
3.Built-in smart charger;
4.Adopt German Bucher brand low - noise hydraulic pump;
5.Multi-function integrated,narrow channel special operation handle;
6.Equipped with standard America CURTIS brand Controller,and controller multiple automatic protection system;
7.Emergency reverse anti-collision device /emergency power cut-off switch;
8.Automatic deceleration in corners;
Applications
After-sales Service
We offer 2 years or 2000 working hours period of warranty to our partners. In case of any defects or quality problems during the warranty period, Maximal will supply technical and spare parts supports to help our partners solving the problems immediately. 7x24 onlineservice are ready for you to ensure your equipments in excellent working condition.
.jpg)
.jpg)
.jpg)
Pre-Sales Service
* Inquiry and consulting support.
* Inspection support
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
