Semi-electric Pallet Stacker
BrandFLIFT
Lifting Height1500mm-3000mm
Power Typesemi electric hydraulic stacker
Turning Radius 1416mm
Fork size(LxWxH)1000mm*160mm*58mm
We're here to help:Easy ways to get the answers you need.
- What load weight and lift height should I consider for a semi-electric walkie stacker?
- Identify the heaviest pallet you need to handle and the highest shelf or rack you must reach. Choose a stacker with a rated capacity that safely covers your load and a mast height that matches your storage requirements.
Technical Parameters
Description Model No. |
TA10-16/TA15-16/
TA20-16 |
TA10-24/TA15-24/
TA20-24 |
TA10-30/TA15-30/ |
TA10-35/TA15-35/
TA20-35 |
Rated Load Capacity --KG |
1000/1500/2000
|
1000/1500/2000
|
1000/1500/2000
|
1000/1500/2000
|
Load Capacity At Max. Height(KG) |
1000/1500/2000
|
1000/1300/1500
|
500/800/1250
|
400/600/750
|
Max. Lift Height (MM) |
1600
|
2400
|
3000
|
3500/
|
Load Center MM |
500
|
500
|
500
|
500
|
Overall Length (MM)--L1 |
1610/1610/1630
|
1610/1610/1630
|
||
Overall Width (MM) -b1 |
824
|
824
|
||
Height (MM)- Mast Lowered -H1 |
2075
|
1775
|
1825
|
2325
|
Height (MM)- Mast Extended-H5 |
2075
|
2960
|
3060
|
4060
|
Height (MM)- Handle -H2 |
1186
|
1186
|
||
Height(MM)-- Fork -h |
85/85/90
|
85/85/90
|
||
Wheelbase -- (MM) -y |
1250/1250/1280
|
1250/1250/1280
|
||
Fork Size L×W (MM) |
1000*160*58/
1000*160*58/ 1000*172*58 |
1000*160*58/
1000*160*58/ 1000*172*58 |
||
Min. Road Clearance --mm -m |
25/25/25
|
25/25/25
|
||
Front Tread --MM--b3 |
520/510/510
|
520/510/510
|
||
Rear Tread --MM--b2 |
704
|
704
|
||
Min. Turning Radius --MM-Wa |
1416
|
|||
Front Tyre --(MM) |
Φ80*70
|
|||
Rear Tyre --(MM) |
Φ180*50
|
|||
Fork Distance (MM)--b4 |
670/670/682
|
|||
Battery V/AH- Domestic Brand |
12/120
|
|||
Charger V/A |
12/15
|
|||
Lift Motor (KW) |
1.6
|
1.6
|
||
Service Weight (with battery)KG |
310/395/435
|
375/480/550
|
380/485/554
|
395/525/595
|
FEATURES
Character:
1. FLIFT 1ton-2ton Series walkie pallet stakcer, used for narrow place, main for retail and manufacturing industry;
2. Rated Load Capactiy: 1500kg, lift height: 3500mm, narrow width design, 180 degree rotate for operation handle;
3. The advantages including: reliabilty, save energy, perfect performance and lower maintanence cost etc.
Applications
After-sales Service
24-Month or 2,000 Work-Hour Warranty:
Your investment is protected for two years or up to 2,000 hours of operation on all major components, including the rugged frame, durable drive axle, high-strength wheels and rims, powerful brakes and brake pumps, responsive steering axle and steering cylinder, efficient hydraulic pump, precision speed limit valve, sturdy forks, as well as the lift and tilt cylinders, and advanced control valves.
12-Month or 1,200 Work-Hour Warranty:
For one year or 1,200 work hours, we cover essential systems such as the robust engine, reliable hydraulic gearbox, dependable battery, intuitive instrument panel, fan belt, all switches, both inner and outer friction plates, high-performance generator and starter, durable water tank, and the complete hydraulic pipeline.
We are committed to delivering unmatched customer service, offering competitive pricing, ensuring swift delivery, and providing a comprehensive range of top-quality products.
Your satisfaction is our highest priority.
