Straddle Pallet Stacker for Warehouse and Logistics Pallet Handling

Technical Parameters

FLIFT 1000-2000kg Electric Straddle Pallet Stacker Technical Specifications
Product Type	Straddle Pallet stacker
Operation Mode	Pedestrian-Operated
Steering Type	Electronic Steering
Control System	CURTIS Controller
Rated Load Capacity	1000 kg
Load Center	500 mm (standard)
Lifting Height	2500 mm
Mast Type	Two Stage Mast
Lift Cylinders	Dual Lift Cylinders
Fork Length	1150 mm
Attachment Type	Rotating Attachment
Rotation Angle	360°
Battery Voltage	24 V
Battery Capacity	210 Ah
Batterty Type	Lead-Acid Battery
Power Type	Electric
Drive Configuration	Side-Mounted Leg Structure
Application	Special Material Handling / Non-Standard Loads

FEATURES

1,The integrated 360-degree rotator allows operators to rotate loads without moving the stacker, ensuring accurate positioning during stacking, loading, and alignment in confined spaces.
2,Equipped with an American CURTIS brand controller, the stacker delivers precise motor control, smooth acceleration, and reliable system response.
3,Electric rotation eliminates manual load turning,reducing operator fatigue while minimizing load instability and product damage.
4,Straddle legs provide stable support for open-bottom pallets, making this stacker ideal for standard warehouse pallet handling without requiring a counterweight structure.
5,The electric drive system offers zero emissions, low noise, and reduced maintenance compared to internal combustion equipment.
6,With a rotating attachment, the stacker can handle bins, drums, crates, reels, and non-standard loads.

Applications

After-sales Service

24-Month or 2,000 Work-Hour Warranty:
Your investment is protected for two years or up to 2,000 hours of operation on all major components, including the rugged frame, durable drive axle, high-strength wheels and rims, powerful brakes and brake pumps, responsive steering axle and steering cylinder, efficient hydraulic pump, precision speed limit valve, sturdy forks, as well as the lift and tilt cylinders, and advanced control valves.

12-Month or 1,200 Work-Hour Warranty:
For one year or 1,200 work hours, we cover essential systems such as the robust engine, reliable hydraulic gearbox, dependable battery, intuitive instrument panel, fan belt, all switches, both inner and outer friction plates, high-performance generator and starter, durable water tank, and the complete hydraulic pipeline.Our dedicated team of sales professionals and technical experts is always ready to guide you in choosing the perfect forklift for your needs.
We are committed to delivering unmatched customer service, offering competitive pricing, ensuring swift delivery, and providing a comprehensive range of top-quality products.
Your satisfaction is our highest priority.

Inquiry

Electric Straddle Pallet Stacker Improves Warehouse Stacking Efficiency
