Rated Capacity: 2000kg,  Load Center: 600mm.
Lifting Height: 9000mm (customizable 4600mm–12500mm).
Mast Type: 2-stage full free mast (3-stage optional).
Mast Rotation: 210°, left and right, equipped with a German ThyssenKrupp mast.
Tires: Solid rubber tires, suitable for both indoor and outdoor operations.
Travel Speed: 12km/h (fully loaded), Gradeability: 12% (full load) / 13% (empty).
Drive Motor Power: 16.3kW AC motor, delivering strong and smooth lifting performance.
Battery: 80V/460Ah, lithium battery optional, Smart Configurations for Operator Comfort.

The FLIFT articulated forklift series is designed with advanced features to maximize efficiency and safety:
Laser-assisted fork alignment and laser-assisted vehicle positioning for precision handling
High-definition camera display for enhanced visibility.The American Curtis electronic controller provides stable, reliable, and smooth operation.
These user-focused configurations ensure operators can work confidently in narrow warehouse aisles while maintaining maximum productivity.

Narrow Aisle Advantage: Why Choose an Aisle Master Forklift?
One of the biggest advantages of the FLIFT aisle master forklift is its ability to operate in rack aisles as narrow as 1900–2100mm.
Compared to a traditional electric reach truck, which requires at least 3100mm of aisle width, the articulated forklift dramatically improves warehouse space utilization.
Additionally, the FLIFT articulated reach truck offers customized lifting heights of up to 12.5m, far exceeding what standard reach trucks can achieve.





The 2ton Aisle Master Truck Maximum Lifting Capacity at Different Heights
12.5m height: 900kg, 10m height: 1200kg,
9m height: 1250kg,     7m height: 1500kg,
6m height: 1600kg,    4.6m height: 1800kg,
This makes the truck suitable for both high-rack warehouses and narrow aisle storage systems, ensuring safe and stable operations at various heights.

What's the turning radius of the narrow aisle articulated forklift?
Turning Radius: Only 2200mm, ideal for narrow aisle operation.What's the minimum rack aisle width for the aisle master forklift in the warehouse?
The width of the rack aisle is only 1900 1900mm-2100mm, thanks to the humanized vehicle body design,
making the aisle master truck can work in the ultra-narrow aisle.

Can we use the electric reach truck instead of the aisle master truck?
If we compare with the regular electric reach truck series,  in the matter of the rack aisle width issue.
The electric reach forklift needs a 3100mm width. The aisle master forklift dramatically enhanced the warehouse utilization rate.
On the side, the aisle master forklift owns the ultra-high lifting height too, and can customize the lift height up to 12500mm.
On the contrary, the electric reach truck can't meet.





Customization and OEM Service
Do u provide the vehicle body color customization service for the aisle master forklift?
In addition, do they support the OEM service too?
We completely meet the requirements. Usually, we have two kinds of vehicle appearance colors for the aisle master truck.
The industrial orange-red and the green, these are our prevailing colors, just provide the color u favor or color series.
We support the OEM service for articulated forklift trucks, too, allowing clients to add their company logo and branding.

Why UAE Businesses Trust FLIFT Articulated Forklifts?
The delivery of these two 2000kg articulated reach trucks to the United Arab Emirates highlights FLIFT's commitment to providing high-quality, space-saving,
and reliable narrow aisle forklift solutions for global customers.With their ability to work in ultra-narrow aisles, lift to 12.5 meters, and provide excellent stability,
FLIFT articulated trucks are the perfect choice for modern warehouses, distribution centers, and logistics hubs in the Middle East and worldwide.



Why UAE Chose FLIFT 9m Articulated Forklifts: Power, Precision, and Performance!

2ton Aisle Master forklift specs: explore load capacity, turning radius, and key features to boost your warehouse productivity.
Check details here!


Aisle master forklift specifications

aisle-master-forklift-specifications.pdf (630KB)
