Factory Direct Sale 2 Ton Electric Pallet Stacker With 24V/210Ah Battery

Date: 2023-05-09 View:

Cheap Price 2 Ton Electric Pallet Stacker With 24V/210Ah Battery

Product Advantages
AC motor eliminates of carbon brush replacement.
 Multi-function display is easy to maintain.
Side way vattery is easy to maintain.
Damping cushion for low-noise operation.
Emergency reversing device equipped handle to keep safe.
Auto deceleration function makes operation more safely.
Product Parameter
Model CDD20B
Dynamic Type Storage Battery
Operation Type Walking handle type
Rated Capacity 1500 kg
Load Center 500 mm
Inatallation grade&form 2A
Tyre mode PU
Tyre size(Front) 210*85 mm
Tyre size(Driving wheel) 230*75 mm
Tyre size(universal wheel) 130*55 mm
Number of tires 2/1X+2 mm
Mast mode 2 Stages
Standard Lifting Height 2500 mm
Mast Lowered Height 1830 mm
Mast Extended Height(with backrest) 3485 mm
Min.Ground Clearance 70 mm
Overall length (Pedal extended/retracted) 3200/2795 mm
Wheel Base 1300 mm
Front Overhang 145 mm
Overall Width (Front/Rear) 990/900 mm
Tread(Front/Rear) 895/684 mm
Fork Size 1070*100*35 mm
Maximum Forks width 240-700 mm
Aisle Width(1000*1200 pallet)(Pedal extended/ retracted) 3510/3095 mm
Turning Radius(Pedal extended/retracted) 2010/1595 mm
Driving Speed(Full load/no load) 4.0/5.0 km/h
Lifting speed(Full load/ no load) 77/150 mm/s
Descend speed(Full load/ no load) 200/105 mm/s
Driving Motor capacity 1.5 kw
Lifting Motor capacity 3 kw
Storage Battery 24V/210Ah
Battery Weight 200 kg
Overall Weight (with battery) 1885 kg
Steering Type Electronic Steering
Parking brake type Electric Brake
Battery Replacement Mode Lifting
Gradeability(S2-5)Full/no load 5%/8%
