FLIFT has officially completed the production of its upgraded 20 ton diesel side loader forklift, built according to a client’s specific operational requirements. This new configuration features a customized 3-stage mast with 3600mm lifting height and is powered by the reliable American Cummins L9 series engine, delivering stronger performance and improved working flexibility for heavy-duty material handling environments.For industries handling long and oversized materials such as steel profiles, pipes, timber, and precast components, this 20T side loader provides both structural strength and operational precision.
Customized 3-Stage Mast- Lower Height, Greater Flexibility

The standard configuration of the FLIFT 20T side loader forklift comes with:

 2-stage mast

3500mm lifting height
Mast lowered height: 3690m
Overall dimension: 3780mm × 3570mm × 3690mm,
However, many heavy industry clients require better clearance performance, especially when operating inside workshops or loading containers.
To meet this demand, FLIFT engineered a strengthened 3-stage mast with 3600mm lifting height.

3-Stage Mast Configuration:

Lifting height: 3600mm
Mast lowered height: 3100mm
Overall dimension: 3780mm × 3570mm × 3100m
Compared with the 2-stage mast, the 3-stage mast reduces the collapsed height by nearly 600mm, significantly improving access to low-clearance buildings and transport containers.





Why choose a 3-stage mast for a 20 ton side loader forklift?
The answer is simple
Lower overall height,  More flexible indoor operation
Better container loading compatibility and Maintained heavy-duty structural stability.
The reinforced mast structure ensures durability even under full 20,000kg load conditions.

American Cummins L9 Engine – 180kW Powerful Output
Power is the core of any heavy duty side loader forklift. For this series, FLIFT selected the globally recognized Cummins L9 engine.
Engine Specifications:
Model: Cummins L9 Series
Rated Power: 180kW / 2200 r.p.m.
Turbocharged system, Strong torque output with Excellent fuel economy.
The Cummins L9 engine provides stable performance under high-load continuous operations. Its turbocharged design ensures fast throttle response and sufficient torque when transporting long and heavy materials.

Heavy Duty Design for Industrial Applications
FLIFT 20T diesel side loader truck is engineered for demanding environments.
Key Technical Parameters:Rated capacity: 20,000kg
Service weight: 33,000kg
Minimum turning radius: 7745mm
Drive type: Diese
Mast options: 2-stage / 3-stage customize
The 33-ton service weight ensures overall structural balance and stability when handling long materials.The 7745mm turning radius provides maneuverability considering the large chassis design required for 20 ton capacity.





Dimensions Comparison – 2 Stage vs 3 Stage Mast

Configuration	Lifting Height	Mast Lowered Height	Overall Dimension (L×W×H)
2-Stage Mast	3500mm	3690mm	3780×3570×3690mm
3-Stage Mast	3600mm	3100mm	3780×3570×3100mm

Why Choose FLIFT 20 Ton Side Loader Forklift
In the side loader forklift customization field, FLIFT has accumulated extensive engineering experience and holds multiple technical patents.

We provide: Custom mast height solutions and Engine brand customization (Cummins, etc.)
Reinforced chassis designWith Export-standard production. Whether your operation requires handling steel pipes, long aluminum profiles, timber bundles, or construction materials,
our heavy duty side loader forklift can be customized accordingly

Here are the Frequently Asked Questions about our 20T side loader.

What is the maximum capacity of this side loader forklift?
20,000kg rated load capacity.

What engine is equipped on the FLIFT 20T diesel side loader?
American Cummins L9 series, 180kW at 2200rpm.

What is the mast lowered height of the 3-stage configuration?
3100mm.

What is the service weight of the 20t diesel side loader forklift?
33,000kg.

What is the minimum turning radius?
7745mm.

Send Your Side Loader Truck Inquiry to FLIFT

As a professional heavy-duty forklift manufacturer, FLIFT focuses on customized side loader forklift solutions for global industrial clients.

If you are looking for: Heavy duty diesel side loader manufacturer, pleae Contact FLIFT today for technical consultation and quotation.
Your heavy-duty material handling solution starts here.
