High Efficient walking type load center 500mm electric pallet stacker with fork length 1150mm

Date: 2022-06-09 View:

Innovative New Design walking type turning radius 1645mm electric pallet stacker with lifting height 3000mm


Advantages
AC drive motor, strong climbing force, lifting height: 1600-4500mm. High strength fork legs, cargo forks, special door frame channel steel for high strength forklifts, large capacity maintension-free battery, built-in intelligent charger,
Multi-function integrated, special handle for narrow channel, low noise lifting hydraulic pump station, good climbing performance.


Security
Drive stepless speed regulation, safety, quiet, controller multiple automatic protection system, emergency reverse anti-collision device/emergency power off switch, automatic deceleration in curves, fixed fork, optional lithium battery, optional 24V165/210ah lead-acid battery, suitable for single-side tray, non-standard customization.


Product Parameters
Model
CDD20D-30
Power Type
Electric
Rated Capacity kg 2000
Load Center  mm 500
Lifting Height mm 3000
Wheelbase mm 1430
Fork Size mm 1150*190*65
Turning Radius mm 1645
Driving Speed(full load) km/h 4.0
Lifting Speed(full load) mm/s 80/125
Battery Weight kg 75
Self Weight(with Battery) kg 580

Certification
