Industrial Machine Electric Forklift Loader Rated Capacity 5ton with Hydraulic Braking

Date: 2022-08-08 View:

 Professional Machine Electric Loader Rated Capacity 5ton with Lead-acid Battery

Features of electric loader:
1. Energy-saving, saving 70% of the operating cost compared with fuel-fueled models under the same working conditions;
2. The battery adopts lithium iron phosphate battery, the battery core adopts a good brand, supports quick charge and quick change, improves the efficiency of electric energy utilization, and its advantages such as mute and energy saving meet the requirements of environmental protection.


3. The permanent magnet synchronous/switched reluctance control system guarantees smooth and accurate walking and lifting control, excellent speed regulation performance, small current and large torque, good electrical control matching performance of the motor, regenerative braking, reverse braking, and slope prevention And other functions.
4. The power system has high efficiency and complete protection functions, with its own speed sensor and temperature sensor, which greatly improves the stability and lifespan.
5. The large-screen LED meter with a good brand is adopted, with power display meter, chronograph and fault self-diagnosis function, which can accurately display in harsh environments.


6. The main electrical components such as the motor controller, contactor, power plug, emergency power off switch, instrument panel, accelerator and so on are all of good brand products.
7. The emergency power-off switch is a standard configuration and conforms to European standards.
8. Electronic and hydraulic overload protection device.
9. Lithium battery is guaranteed for 5 years or 10,000 hours. The whole machine is guaranteed for 18 months.



Product Parameters
ITEM
DATA
dipper capacity
2.7---4.5
rated load kg    5000 
Boom lifting time (no load) s  ≦ 6s 
Boom descent time (no load) s  ≦ 7.5 
Rake time of bucket s  ≦3.5 s 
TRINOMIAL SUM s ≦1.5s 
Bucket upturn Angle (when the bucket is the highest) s ≦11
Bucket down turn Angle (when the bucket is the highest) °  60.5° 
DUMP DISTANCE ° 45
MAXIMUM UNLOADING HEIGHT mm 1100
MAX LIFTING HEIGHT mm 3100-4000
MAX STOPPING HEIGHT mm 5350
EXCAVATION DEPTH mm 350 
WHEEL BASE mm 46 

Certification
