Factory price 2.5 ton full electric forklift truck with 5m lifting height for sale

Date: 2022-04-06 View:

 Battery power China new hydraulic 2.5 ton small electric forklift truck


Original imported world famous brand controller. After professional adjustment and walking, the control accuracy and efficiency are improved, and it has excellent performance, regenerative braking, slope braking, fault self-diagnosis and other functions.


Using dynamic load sensing priority steering system, steering response more quickly, driving more smoothly.


Ergonomic full-scale operation space layout optimization, which offers operator excellent,comfortable and convenient operating experience.


Advanced H-type remote drive unit, compact structure, lower gravity center, more reasonable layout, more stable driving.


Fully open hood, it can quickly remove from both side. Hinge design frame side door. The using of advanced design concept of battery replacement program, gives fast and convenient maintenance.


Standard export packaging, to be fixed in the container by triangle wood/iron brackets withstand rough handling in the transit of forklifts.

FLIFT 2.5 ton electric forklift specification
Model
FB25
Rated Capacity kg 2500
Load Centre mm 500
Lift Height mm 5000
Fork Size (L*W*T) mm 1070*120*40
Mast Tilt Angle (F/R) Deg 6°/12°
Front Overhang (Wheel Center to fork face) mm 465
Tread (Min./Max.)
240/1020
Length to face of fork(Without fork) mm 2360
Overall Width mm 1160
Mast Lowered Height mm 2295
Mast Extended Height(With backrest) mm 6020
Overall Guard Height mm 2240
Turning Radius(outside) mm 2075
Min. insecting aisle mm 2250
Travel(Empty load) km/h 15
Lifting(Full load) mm/s 300
Max. Gradeability % 15
Wheel Base mm 1510
Service Weight kg 4450
Voltage/Capacity V/Ah 48/630
Drive Motor kw 11

FLIFT forklift CE approved:
