1.2

Model Number

T100

1.3

Power Type

Electric

1.4

Operating Type

Pedestrian

1.5

Rated Load

Q(kg)

10000

1.6

Lifting Capacity

kg

5000

1.7

Rated Traction Force

F(N)

4000

1.8

Wheelbase

y(mm)

2440

2.1

Weight (including battery)

kg

1000

2.2

Battery weight

kg

272

3.1

Tire type,drive wheel/load-bearing wheel

Solid rubber wheels

3.2

Drive wheel size (diameter×width)

mm

21*8-9

3.3

Load-bearing wheel size(diameter ×width)

mm

φ400×150

3.5

Number of drive wheels/load-bearing wheels(x=drive wheels)

mm

2×/1

3.6

Front track,drive end

b10(mm)

915

4.1

Overallvehicle height

h1(mm)

1330

4.2

Operating handle height

h2(mm)

950/1150

4.3

Traction coupler height range

h3(mm)

1000-1400

4.4

Overall vehicle length

11(mm)

3395

4.5

Overall vehicle width

b1(mm)

1450

4.6

Minimum ground clearance

m1(mm)

100

4.7

Turning radius

WA(mm)

2650

5.1

Travel speed,fully loaded/unloaded

km/h

3.5/5.0

5.2

Rated traction force

N

4000

5.3

Maximum traction force

N

6000

5.4

Climbing ability,fully loaded/unloaded

%

3/10

5.6

Brake type

electromagnetic

6.1

Drive motor rated power S260 minutes

KW

3

6.2

Charger(external)

V/A

48/30

6.3

Battery voltage/nominal capacity K20

V/Ah

48/203

6.4

Air compressor

48V/8KG

6.5

Hydraulic motor

KW

2.2

7.1

Drive control type

AC

7.2

Steering type

mechanical

7.3

Noise level

dB(A)

<70

7.4

Traction coupling type

Latch
