2022 FB20S 2000kg electric forklift 3 wheel forklift 2 ton battery forklift with Wide-view 2-stage 3meter mast for sale

Date: 2022-04-14 View:

High Performance FB20s 2T 3 Wheel Fork Length 920 mm Electric Forklift with CE certificate Made in China

   Fully open hood, it can quickly remove from both side. Hinge design frame side door. The using of advanced design concept of battery replacement program, gives fast and convenient maintenance;



1.Efficient Driving System

Advanced dual motor driving system, compact structure, better driving and climbing performance, larger torque, more powerful output;
>New maintenance-free AC motor with high transmission efficiency and low maintenance and maintenance costs;
>Imported German ZF axle box integrated high-performance drive system;
"Maintenance-free wet disc-to-brake system.




2.Flexible Steering System

Adopting dynamic load sensing priority steering system, more quickly steering, smaller turning radius, more flexible driving performance.
>Original imported corner potentiometer;

>The turning angle of the rear wheel can reach 90°, which can realize 180° steering of the forklift on the spot, and the maneuverability is super strong.



3.Comfortable Operating Space

Ergonomic full-scale operation space layout which give the operator a good, comfortable and convenient operating experience.
>Sinking design of tilting cylinder;
>Fully surround instrument panel cover;
>Wide vision gantry design;
>Right hydraulic joystick, safety power-off switch and storage box;
> Secondary boarding pedals;
>Inclination adjustable small diameter steering wheel;
> Front and rear adjustable wrap-around seat (adjustable range up to 150mm).



4.High Quality Electrical Components
Original imported word famous brand controller After professional adjustment, walking and upgrade control precision and efficiency it has excellent performance, regenerative braking. ramp braking, fault self-diagnosis and other functions.
>Regenerative braking: When the forklift decelerates, descends, reverses and other conditions, the walking motor turns into a generator, and the battery is reversely charged through the controller, which is highly efficient and energy-saving
>Imported brand accelerator;
>Imported power connector;
>AMP waterproof wiring harness.



Product Parameter

Model   FB20S
Power Type   ELectric
Rated Capacity kg 2000
Load Centre mm 500
Lift Height mm 3000
Fork Size mm 1070*120*40
Mast Tilt Angle Deg 5°/7°
Front Overhang mm 410
Tread mm 930/208
Ground Clearance mm 90
Fork Spread   200/950
Length to face of fork mm 2090
Overall Width mm 1100
Mast Lowered Height mm 2030
Mast Extended Height mm 4010
